1.High performance diodes,powerful output,low divergence<1.0mrad(full angle)

2.Larger scan angle,sharp and pure laser beam,excellent heat dissipation

3.Pangolin FB3/FB4 available,control by ILDA,DMX,SD CARD etc.
4.Professional dust-free case design,easy to install and portable
5.Longer life time,used in indoor or outdoor shows.

DK-RGB 20W

Specifications:

Red (637nm):7000mw

Green(520nm):5000mw

Blue(445nm):8000mw

Total power:RGB 20W

Beam divergence:<1mrad(full angle)

Beam diameter:<5mm

Input Voltage：AC90-245V

Modulation : Analog 50KHZ

Power consumption:50W

Controller:Pangolin FB3/FB4 for optional

Scanning:

PT-A30,35kpps,Max scan angle:60 degree

40K, EMS 8000 60K available required

Operation Modes:

Auto,sound active,DMX512，Master/slave，ILDA，SD card

L*W*H: 40cm*38cm*34 cm

Packing with flight case: 54cm*46cm*43cm Weight:36kg

Lifetime：>5000 hours

Operation Temperature：10-35℃

Cooling way：Fan cooling

Protection rating:IP52

Laser safety:

Key switch, Interlock interface.Overload protection on X and Y Galvo for best safeguarding against failure.Mechanical shutter optionally available.

Compliance:  FDA/CDRH, CE, ROHS

Warranty:  1 years after-sale service
